File:3DPSF 3DMTF widefield confocal.png

Size of this preview: 702 × 600 pixels. Other resolution: 837 × 715 pixels.

Original file (837 × 715 pixels, file size: 151 KB, MIME type: image/png)

Summary[edit]

Summary
Description	The three-dimensional point spread functions (a,c) and corresponding modulation transfer functions (b,d) of a wide-field microscope (a,b) and confocal microscope (c,d). In both cases the numerical aperture of the objective is 1.49 and the refractive index of the medium 1.52. The wavelength of the emitted light is assumed to be 600 nm and, in case of the confocal microscope, that of the excitation light 500 nm with circular polarization. The colors as shown on the logarithmic color bar indicate the irradiance (a,c) and spectral density (b,d) normalized to the maximum value. author:
Source	Wikimedia Commons file page
Author	Tom Vettenburg
Permission	See original Commons license details.

Creative Commons Attribution 3.0 Unported (CC BY 3.0)

This file is licensed under the Creative Commons Attribution 3.0 license.

Official license: CC BY 3.0

License page: CC BY 3.0

Original attribution and file history: Wikimedia Commons
