File:FTIR-interferogram.svg
From WikiMD's WELLNESSPEDIA
Size of this PNG preview of this SVG file: 800 × 594 pixels. Other resolution: 2,560 × 1,902 pixels.
Original file (SVG file, nominally 969 × 720 pixels, file size: 25 KB)
Summary[edit]
| Summary | |
|---|---|
| Description | An FTIR interferogram. The horizontal axis is the position of the moving mirror in the FTIR, the vertical axis is the amount of light measured by the detector. DETAILS: This was a "background" measurement, using a commercial FTIR. To make the fringes visible, I zoomed in the interferogram both vertically (the ZPD peak goes much higher and lower than shown) and horizontally. The mirror displacement units were not given, so I inferred it from the resolution quoted by the software. The vertical axis is arbitrary units -- unknown scale AND unknown offset! |
| Source | Wikimedia Commons file page |
| Author | Sbyrnes321 |
| Permission | See original Commons license details. |
Licensing[edit]
License: CC0
License page: CC0
Original attribution and file history: Wikimedia Commons
