File:RBMK Reaktor ChNPP-4.svg

Size of this PNG preview of this SVG file: 600 × 600 pixels. Other resolution: 2,048 × 2,048 pixels.

Original file (SVG file, nominally 2,408 × 2,408 pixels, file size: 20 KB)

Summary[edit]

Summary
Description	RBMK-Core of Chernobyl-4: Positions of control rods (insertion depth in centimeters) approximately 1min30s before the explosion on Saturday, 26. April 1986, last signal of SKALA control system at 1:22:30 h. green: (167) control rods blue: (12) LAR Rod yellow: (32) shortened absorber rods inserted from below the reactor core grey: (1661) pressure tubes red: (12) automatic control rods
Source	Wikimedia Commons file page
Author	WhiteTimberwolf (SVG version), ChNPP (PNG version)
Permission	See original Commons license details.

Public Domain

This file is in the public domain and may be used without restriction.

Please see the linked source page for the original file history, attribution information, and licensing details.

Original attribution and file history: Wikimedia Commons
